Fabric properties
Semi transparent
25% Polyester, 75% PVC
420 g/m²
0.57 mm
295 cm
12.7 cm, 250 cm, 300 cm
Features / Technical properties
7-8
Flame retardant
Optimised for workstations
Antimicrobial
Applicable in humid areas
Digital printing
Oeko-Tex, Greenguard
Weldable
Washing instructions
Optical and solar coefficients (± 5%, DIN EN 410)
| Colour | |||||||
|---|---|---|---|---|---|---|---|
| Colour 1 | Tv(%) 17.7 | Ts(%) 21.4 | Rs(%) 58.8 | As(%) 19.8 | Tuv(%) 6.1 | Fc() 0.56 | gtot() 0.40 |
| Colour 2 | Tv(%) 12.1 | Ts(%) 17.1 | Rs(%) 59.8 | As(%) 23.1 | Tuv(%) 4.6 | Fc() 0.55 | gtot() 0.40 |
| Colour 3 | Tv(%) 8.8 | Ts(%) 12.4 | Rs(%) 44.5 | As(%) 43.1 | Tuv(%) 5.7 | Fc() 0.64 | gtot() 0.46 |
| Colour 4 | Tv(%) 7.6 | Ts(%) 11.2 | Rs(%) 29.2 | As(%) 59.6 | Tuv(%) 4.7 | Fc() 0.74 | gtot() 0.53 |
| Colour 5 | Tv(%) 7.4 | Ts(%) 9.7 | Rs(%) 16.7 | As(%) 73.6 | Tuv(%) 6.2 | Fc() 0.82 | gtot() 0.59 |
| Colour 6 | Tv(%) 5.3 | Ts(%) 6.5 | Rs(%) 14.2 | As(%) 79.3 | Tuv(%) 4.5 | Fc() 0.83 | gtot() 0.60 |
Fc + gtot: Value calculated with glass: 0.72 / Ug = 1.6 W/m² K, DIN EN 13363-1
Classification of solar shading devices (DIN EN 14501:2021)
| Colour | Glare control | Privacy at night | Sight contact with the outside | Daylight utilisation |
|---|---|---|---|---|
| Colour 1 | Glare control 0 | Privacy at night 1 | Sight contact with the outside 2 | Daylight utilisation 2 |
| Colour 2 | Glare control 0 | Privacy at night 2 | Sight contact with the outside 1 | Daylight utilisation 2 |
| Colour 3 | Glare control 0 | Privacy at night 1 | Sight contact with the outside 3 | Daylight utilisation 1 |
| Colour 4 | Glare control 1 | Privacy at night 2 | Sight contact with the outside 2 | Daylight utilisation 1 |
| Colour 5 | Glare control 0 | Privacy at night 1 | Sight contact with the outside 3 | Daylight utilisation 1 |
| Colour 6 | Glare control 1 | Privacy at night 2 | Sight contact with the outside 2 | Daylight utilisation 1 |
0: No effect, 1: Low effect, 2: Medium effect, 3: High effect, 4: Very high effect
